Specifications

Design & Build

• Model: XMPIR02SGXS

• Dimensions: φ32.5 × 69.5 mm

• Net Weight: 19 g

• Material: Plastic housing

• Mounting: Magnetic base with adhesive for flexible positioning

Performance

• Detection Range: Up to 7 meters

• Detection Angle: Approximately 130°

• Motion Sensitivity: Standard and micro-motion detection

• Illuminance Detection: 0–1000 lux

• Detection Interval: Selectable 10s/20s/30s

• Operating Temperature: -10°C to 45°C

• Operating Humidity: 0–95% RH (non-condensing)

Connectivity

• Wireless Protocol: Bluetooth 5.0 (requires Bluetooth Mesh gateway)

Power & Battery

• Battery Type: CR2450 coin cell (included)

• Battery Life: Up to 3 years under typical usage (based on 1600 triggers and 300 light reports per day)

Package Contents

• Xiaomi Motion Sensor 2S ×1

• User Manual ×1
